Figure 346 Network diagram
Device Interface IP address
Device
Interface
IP address
Source 1 192.168.1.100/24 Firewall B GE0/1 10.110.5.1/24
Source 2 192.168.3.100/24
GE0/2
10.110.3.2/24
Firewall A GE0/1 10.110.1.1/24
Loop0
2.2.2.2/32
GE0/2 10.110.2.1/24 Router C GE0/1 10.110.5.2/24
Loop0 1.1.1.1/32
GE0/2
192.168.3.1/24
Router
A
GE0/1 10.110.1.2/24
Router D
GE0/1
10.110.6.1/24
GE0/2 192.168.1.1/24 GE0/2 10.110.4.2/24
GE0/3 10.110.3.1/24
Firewall C
GE0/1
10.110.6.2/24
Router B GE0/1 10.110.2.2/24
GE0/2
192.168.4.1/24
GE0/2 192.168.2.1/24
Loop0
3.3.3.3/32
GE0/3 10.110.4.1/24
Configuration procedure
1. Configure IP addresses and unicast routing:
Configure the IP address and subnet mask for each interface as per Figure 346. (Details not
shown.)
Config
ure OSPF on routers and firewalls in each AS to make sure the network-layer in each AS is
interoperable and routing information among the routers and firewalls can be dynamically
updated. (Details not shown.)
2. Enable IP multicast routing, enable PIM-SM and IGMP, and configure a PIM-SM domain border:
# Enable IP multicast routing on Router B, enable PIM-SM on each interface, and enable IGMP on
the host-side interface GigabitEthernet 0/2.
<RouterB> system-view
[RouterB] multicast routing-enable
[RouterB] interface gigabitethernet 0/1
[RouterB-GigabitEthernet0/1] pim sm
GE0/3
G
E
0
/
2
