NOTE:
• The maximum interval for sendin
g
RA messa
g
es should be less than or equal to the router lifetime in R
A
messages, so that the router can be updated through an RA message before expiration.
• The values of the NS retransmission timer and the reachable time confi
g
ured for an interface are sent to
hosts via RA messages. Furthermore, this interface sends NS messages at the interval of the NS
retransmission timer and considers a neighbor reachable within the reachable time.
Configuring the maximum number of attempts to send an NS
message for DAD
An interface sends an NS message for DAD after acquiring an IPv6 address. If the interface does not
receive a response within a specified time (determined by the ipv6 nd ns retrans-timer command), it
continues to send an NS message. If it still does not receive a response after the number of sent attempts
reaches the threshold (specified with the ipv6 nd dad attempts command), the acquired address is
considered usable.
To configure the attempts to send an NS message for DAD:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter interface view.
interface interface-type
interface-number
N/A
3. Configure the number of
attempts to send an NS
message for DAD.
ipv6 nd dad attempts value
Optional.
1 by default. When the value
argument is set to 0, DAD is
disabled.
Enabling ND proxy
NOTE:
ND proxy supports the NS and NA messages only.
Introduction
If a host sends an NS message requesting the hardware address of another host that is isolated from the
sending host at Layer 2, the device in between must be able to forward the NS message to allow Layer
3 communication between the two hosts. This is achieved by ND proxy.
As shown in Figure 355, R
ou
ter connects to two subnets through Ethernet 1/1 and Ethernet 1/2. The IP
addresses of the two interfaces are 4:1::99/64 and 4:2::99/64. Host A and Host B have the same prefix
assigned and are connected to Ethernet 1/1 and Ethernet 1/2, respectively.
