R3721-F3210-F3171-HP High-End Firewalls Network Management Configuration Guide-6PW101

694
Ste
p
Command Remarks
3. .Configure a prefix.
• (Approach 1) Configure a static prefix
static-bind prefix prefix/prefix-len duid
duid [ iaid iaid ] [ preferred-lifetime
preferred-lifetime valid-lifetime
valid-lifetime ]
• (Approach 2) Apply a prefix pool to the
address pool
prefix-pool prefix-pool-number
[ preferred-lifetime preferred-lifetime
valid-lifetime valid-lifetime ]
Use either approach.
No prefix is specified by
default.
4. Configure a DNS server
address.
dns-server ipv6-address
Not configured by
default.
5. Configure a domain name.
domain-name domain-name
Not configured by
default.
6. Configure the IPv6 address
or domain name of a SIP
server.
sip-server { address ipv6-address |
domain-name domain-name }
Not configured by
default.
7. Specify the AFTR address.
ds-lite address ipv6-address Not specified by default.
NOTE:
• Only one prefix pool can be referenced by an address pool.
• A non-existin
g
prefix pool can be referenced by an address pool. However, no prefix is available in the
prefix pool for dynamic prefix assignment until the prefix pool is created.
• You cannot modify the prefix pool referenced by an address pool, or the preferred lifetime or valid
lifetime by using the prefix-pool command. You need to remove the confi
g
uration before you can have
another prefix pool referenced by the address pool, or modify the preferred lifetime and valid lifetime.
• You can confi
g
ure up to ei
g
ht DNS server addresses, one domain name, ei
g
ht SIP server addresses, and
eight SIP server domain names in an address pool.
• For more information about AFTR, see
VPN Configuration Guide .
Applying the address pool to an interface
After an address pool is applied to an interface, a prefix and other configuration parameters can be
selected from the address pool and assigned to the DHCPv6 client requesting through the interface.
To apply an address pool to an interface:
Ste
p
Command Remarks
1. Enter system view. system-view N/A
2. Enter interface view.
interface interface-type interface-number N/A
3. Apply the DHCPv6 address
pool to the interface.
ipv6 dhcp server apply pool pool-number
[ allow-hint | preference preference-value
| rapid-commit ] *
Not configured by default
