R3721-F3210-F3171-HP High-End Firewalls Network Management Configuration Guide-6PW101

775
Ste
p
Command Remarks
3. Enter IPv6 address family
view.
ipv6-family N/A
4. Allow the local AS number to
appear in AS_PATH of routes
from a peer/peer group and
specify the repeat times.
peer { ipv6-group-name |
ipv6-address } allow-as-loop
[ number ]
Optional.
Not allowed by default.
5. Specify a fake AS number for
an IPv6 peer/peer group.
peer { ipv6-group-name |
ipv6-address } fake-as as-number
Optional.
Not specified by default.
6. Disable IPv6 MBGP from
considering the AS_PATH
during best route selection.
bestroute as-path-neglect
Optional.
Enabled by default.
7. Configure to carry only the
public AS number in updates
sent to a peer/peer group.
peer { ipv6-group-name |
ipv6-address } public-as-only
Optional.
By default, IPv6 BGP updates carry
private AS number.
8. Substitute the local AS number
for the AS number of an IPv6
peer/peer group identified in
the AS_PATH attribute.
peer { ipv6-group-name |
ipv6-address } substitute-as
Optional.
Not substituted by default.
Tuning and optimizing IPv6 BGP networks
This section describes configurations of IPv6 BGP timers, IPv6 BGP connection soft reset and the
maximum number of load balanced routes.
• IPv6 BGP timers
After establishing an IPv6 BGP connection, two routers send keepalive messages periodically to each
other to maintain the connection. If a router receives no keepalive message from the peer after the
holdtime elapses, it tears down the connection.
When establishing an IPv6 BGP connection, the two parties compare their holdtimes, taking the shorter
one as the common holdtime. If the holdtime is 0, neither keepalive massage is sent, nor holdtime is
checked.
• IPv6 BGP connection soft reset
After modifying a route selection policy, you have to reset IPv6 BGP connections to make the new one
take effect. The current IPv6 BGP implementation supports the route-refresh feature that enables dynamic
route refresh without needing to disconnect IPv6 BGP links.
After this feature is enabled on all IPv6 BGP routers, a router that wants to apply a new route selection
policy advertises a route-refresh message to its peers, which then send their routing information to the
router. After receiving the routing information, the router can perform dynamic route update by using the
new policy without tearing down connections.
If a peer not supporting route-refresh exists in the network, you need to configure the peer keep-all-routes
command to save all routes from the peer. When the routing policy is changed, the system will update the
IPv6 BGP routing table and apply the new policy.
Configuration prerequisites
Before you configure IPv6 BGP timers, complete the following tasks:
