Task Command Remarks
Display IS-IS enabled interface
information.
display isis interface [ statistics |
[ interface-type interface-number ]
[ verbose ] ] [ process-id | vpn-instance
vpn-instance-name ] [ | { begin | exclude |
include } regular-expression ]
Available in any view
Display LSDB information.
display isis lsdb [ [ l1 | l2 | level-1 | level-2 ]
| [ [ lsp-id lsp-id | lsp-name lspname |
local ] | verbose ] * ] * [ process-id |
vpn-instance vpn-instance-name ] [ | { begin
| exclude | include } regular-expression ]
Available in any view
Display IS-IS mesh group
information.
display isis mesh-group [ process-id |
vpn-instance vpn-instance-name ] [ | { begin
| exclude | include } regular-expression ]
Available in any view
Display the mapping table
between the host name and system
ID.
display isis name-table [ process-id |
vpn-instance vpn-instance-name ] [ | { begin
| exclude | include } regular-expression ]
Available in any view
Display IS-IS neighbor information.
display isis peer [ statistics | verbose ]
[ process-id | vpn-instance
vpn-instance-name ] [ | { begin | exclude |
include } regular-expression ]
Available in any view
Display IPv6 IS-IS routing
information.
display isis route ipv6 [ [ level-1 | level-2 ] |
verbose ] * [ process-id | vpn-instance
vpn-instance-name ] [ | { begin | exclude |
include } regular-expression ]
Available in any view
Display SPF log information.
display isis spf-log [ process-id |
vpn-instance vpn-instance-name ] [ | { begin
| exclude | include } regular-expression ]
Available in any view
Display the statistics of the IS-IS
process.
display isis statistics [ level-1 | level-1-2 |
level-2 ] [ process-id | vpn-instance
vpn-instance-name ] [ | { begin | exclude |
include } regular-expression ]
Available in any view
Clear all IS-IS data structure
information.
reset isis all [ process-id | vpn-instance
vpn-instance-name ]
Available in user view
Clear the IS-IS data information of
a neighbor.
reset isis peer system-id [ process-id | vpn
vpn-instance-name ]
Available in user view
IPv6 IS-IS configuration examples
IPv6 IS-IS basic configuration example
Network requirements
As shown in Figure 389, Firewall A, Firewall B, Firewall C and Firewall D, all enabled with IPv6, reside
in the same AS. Configure IPv6 IS-IS on the routers to make them reachable to each other.
Firewall A and Firewall B are Level-1 routers, Firewall D is a Level-2 router, and Firewall C is a Level-1-2
router. Firewall A, Firewall B, and Firewall C belong to area 10, and Firewall D is in area 20.
