Table 88 Relationship between the match mode and the clauses
If a packet…
Then…
In
p
ermit mode In den
y
mode
Matches all the if-match clauses on
the policy node
The apply clause is executed, and
the packet will not go to the next
policy node for a match.
The apply clause is not executed,
the packets will not go to the next
policy node for a match, and will
be forwarded according to the
routing table.
Fails to match an if-match clause
on the policy node
The apply clause is not executed,
and the packet will go to the next
policy node for a match.
The apply clause is not executed,
and the packet will go to the next
policy node for a match.
NOTE:
• If a policy has a node with no if-match clause configured, all packets can pass the policy node.
However, an action is taken accordin
g
to the match mode, and the packets will not
g
o to the next policy
node for a match.
• If a policy has a node with the permit match mode but no apply clause confi
g
ured, all packets matchin
g
all the if-match clauses can pass the policy node. However, no action is taken, the packets will not
g
o to
the next policy node for a match, and will be forwarded according to the routing table.
• If a policy has a node with no if-match or apply clauses configured, all packets can pass the policy
node. However, no action is taken; the packets will not
g
o to the next policy node for a match, and will
be forwarded according to the routing table.
The nodes of a policy are in an OR relationship. If a packet matches a node, it passes the policy; if the
packet does not match any node of the policy, it fails to pass the policy and is forwarded according to
the routing table.
if-match clause
The following types of if-match clause are available: if-match packet-length and if-match acl6.
You can specify only one if-match clause of each type in a policy node. The if-match clauses on a node
have an AND relationship. A packet must satisfy all the if-match clauses of the node before the action
specified by the apply clause is taken.
apply clause
The following types of apply clauses are available: apply ipv6-precedence, apply output-interface,
apply ipv6-address next-hop, apply default output-interface, and apply ipv6-address default next-hop.
For the priorities of the apply clauses in a policy node, see Table 89.
Table 89 Priorities of the apply clauses in a policy
node
Clause Meanin
g
Priorit
y
apply
ipv6-precedence
Sets an IP precedence. If configured, this clause will always be executed.
apply
output-interface and
apply ipv6-address
next-hop
Sets the outgoing interface
and next hop.
The apply output-interface clause takes precedence
over the apply ipv6-address next-hop clause. Only the
apply output-interface clause will be executed when
both are configured.
