the RP dynamically calculated based on the BSR mechanism. Thus, the DR does not need to know the RP
address beforehand.
Perform this configuration on all routers in the IPv6 PIM-SM domain.
To enable embedded RP:
Ste
p
Command Remarks
1. Enter system view. system-view N/A
2. Enter IPv6 PIM view.
pim ipv6 N/A
3. Enable embedded RP.
embedded-rp [ acl6-number ]
Optional.
By default, embedded RP is
enabled for IPv6 multicast groups
in the default embedded RP
address scopes.
NOTE:
The default embedded RP address scopes are FF7x::/12 and FFFx::/12. Here "x" refers to any legal
address scope.
Configuring C-RP timers globally
To enable the BSR to distribute the RP-set information within the IPv6 PIM-SM domain, C-RPs must
periodically send C-RP-Adv messages to the BSR. The BSR learns the RP-set information from the received
messages, and encapsulates its own IPv6 address together with the RP-set information in its bootstrap
messages. The BSR then floods the bootstrap messages to all IPv6 routers in the network.
Each C-RP encapsulates a timeout value in its C-RP-Adv messages. After receiving a C-RP-Adv message,
the BSR obtains this timeout value and starts a C-RP timeout timer. If the BSR fails to obtain a subsequent
C-RP-Adv message from the C-RP when the timer times out, the BSR assumes the C-RP to have expired or
become unreachable.
You must configure the C-RP timers on C-RP routers.
To configure C-RP timers globally:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter IPv6 PIM view.
pim ipv6 N/A
3. Configure the C-RP-Adv
interval.
c-rp advertisement-interval interval
Optional.
60 seconds by default.
4. Configure C-RP timeout time.
c-rp holdtime interval
Optional.
150 seconds by default.
NOTE:
For more information about the configuration of other timers in IPv6 PIM-SM, see "Confi
g
urin
g
IPv6 PIM
common timers."
