Task Command Remarks
Display MLD configuration and
running information on the
specified interface or all
MLD-enabled interfaces.
display mld interface [ interface-type interface-number ]
[ verbose ] [ | { begin | exclude | include }
regular-expression ]
Available in
any view
Display the information of the
MLD proxying groups.
display mld proxying group [ group-address ] [ verbose ]
[ | { begin | exclude | include } regular-expression ]
Available in
any view
Display the information of the
MLD routing table.
display mld routing-table [ ipv6-source-address
[ prefix-length ] | ipv6-group-address [ prefix-length ] |
flags { act | suc } ] * [ | { begin | exclude | include }
regular-expression ]
Available in
any view
Display MLD SSM mappings.
display mld ssm-mapping ipv6-group-address [ | { begin |
exclude | include } regular-expression ]
Available in
any view
Display the IPv6 multicast group
information created based on the
configured MLD SSM mappings.
display mld ssm-mapping group [ ipv6-group-address |
interface interface-type interface-number ] [ verbose ] [ |
{ begin | exclude | include } regular-expression ]
Available in
any view
Display information about the
hosts that join based on the MLD
SSM mappings on an interface.
display mld ssm-mapping host interface interface-type
interface-number group ipv6-group-address source
ipv6-source-address [ | { begin | exclude | include }
regular-expression ]
Available in
any view
Remove the dynamic group
entries of a specified MLD group
or all MLD groups.
reset mld group { all | interface interface-type
interface-number { all | ipv6-group-address [ prefix-length ]
[ ipv6-source-address [ prefix-length ] ] } }
Available in
user view
Clear MLD SSM mappings.
reset mld ssm-mapping group { all | interface
interface-type interface-number { all | ipv6-group-address
[ prefix-length ] [ ipv6-source-address [ prefix-length ] ] } }
Available in
user view
CAUTION:
The reset mld group command might cause an interruption of receivers' reception of multicast data.
MLD configuration examples
Basic MLD functions configuration example
Network requirements
As shown in Figure 398, receivers receive VOD information in the multicast mode. Receivers of different
organizations form stub networks N1 and N2, and Host A and Host C are multicast receivers in N1 and
N2 respectively.
MLDv1 runs between Firewall A and N1 and between the other two routers (Firewall B and Firewall C)
and N2. Firewall B acts as the MLD querier because it has a lower IPv6 address.
The hosts in N1 can join only IPv6 multicast group FF1E::101, and the hosts in N2 can join any IPv6
multicast groups.
