Creating a routing policy
Ste
p
Command
1. Enter system view.
system-view
2. Create a routing policy, specify a node
for it and enter routing policy view.
route-policy route-policy-name { deny | permit } node
node-number
Defining if-match clauses
Follow these guidelines when you define if-match clauses:
• The if-match clauses of a routing policy node are in logic AND relationship. Routing information
has to satisfy all its if-match clauses before being executed with its apply clauses. If an if-match
command exceeds the maximum length, multiple identical if-match clauses are generated. These
clauses are in logical OR relationship. Routing information only needs to match one of them.
• You can specify any number of if-match clauses for a routing policy node. If no if-match clause is
specified, and the routing policy node is in permit mode, all routing information can pass the node.
If it is in deny mode, no routing information can pass it.
• If the ACL referenced by an if-match clause does not exist, the clause is always satisfied; if no rules
of the referenced ACL are matched or the matching rule is inactive, the clause is not satisfied.
• An ACL specified in an if-match clause should be a non-VPN ACL.
• The if-match commands for matching IPv4 destination, next hop and source address are different
from those for matching IPv6 ones.
• BGP does not support criteria for matching against outgoing interfaces of routing information.
To define if-match clauses:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter routing policy view.
route-policy route-policy-name { deny |
permit } node node-number
N/A
3. Define match criteria for IPv4
routes.
• Match IPv4 routing information specified
in the ACL:
if-match acl acl-number
• Match IPv4 routing information specified
in the IP prefix list:
if-match ip-prefix ip-prefix-name
• Match IPv4 routing information whose
next hop or source is specified in the ACL
or IP prefix list:
if-match ip { next-hop | route-source }
{ acl acl-number | ip-prefix
ip-prefix-name }
Optional.
Not configured by
default.
4. Match IPv6 routing information
whose next hop or source is
specified in the ACL or IP prefix
list.
if-match ipv6 { address | next-hop |
route-source } { acl acl-number | prefix-list
ipv6-prefix-name }
Optional.
Not configured by
default.
