NOTE:
For more information about symmetric key algorithms, asymmetric key algorithm RSA, di
g
ital si
g
nature,
and PKI, see
VPN Configuration Guide .
SSL protocol stack
As shown in Figure 404, the SSL protocol consists of two layers of protocols: the SSL record protocol at
the lower layer and the SSL handshake protocol, change cipher spec protocol, and alert protocol at the
upper layer.
Figure 404 SSL protocol stack
• SSL record protocol—Fragments data to be transmitted, computes and adds MAC to the data, and
encrypts the data before transmitting it to the peer end.
• SSL handshake protocol—Negotiates the cipher suite to be used for secure communication
(including the symmetric encryption algorithm, key exchange algorithm, and MAC algorithm),
securely exchanges the key between the server and client, and implements identity authentication
of the server and client. Through the SSL handshake protocol, a session is established between a
client and the server. A session consists of a set of parameters, including the session ID, peer
certificate, cipher suite, and master secret.
• SSL change cipher spec protocol—Used for notification between the client and the server that the
subsequent packets are to be protected and transmitted based on the newly negotiated cipher suite
and key.
• SSL alert protocol—Enables the SSL client and server to send alert messages to each other. An alert
message contains the alert severity level and a description.
SSL configuration task list
Task Remarks
Configuring an SSL server policy Required
Configuring an SSL client policy Optional
Configuring an SSL server policy
An SSL server policy is a set of SSL parameters for a server to use when booting up. An SSL server policy
takes effect only after it is associated with an application layer protocol such as HTTP.
Before configuring an SSL server policy, configure the PKI domain for the SSL server policy to use to
obtain a certificate for the SSL server. For more information about PKI domain configuration, see VPN
Configuration Guide.
