R3721-F3210-F3171-HP High-End Firewalls Network Management Configuration Guide-6PW101

75
Figure 48 MSTP port configuration
Table 19 Configuration items
Item Descri
p
tion
Port Number Port number.
STP Status
Whether to enable STP on the port:
• Enable—Enable STP on the port.
• Disable—Disable STP on the port.
Protection Type
Type of protection enabled on the port:
• Not Set—No protection is enabled on the port.
• Edged Port, Root Protection, Loop Protection—For more information, see Table
20.
Point to Point
Specify whether the port is connected to a point-to-point link.
• Auto—Automatically detects whether the link type of the port is point-to-point.
• Force False—Specifies that the link type for the port is not point-to-point link.
• Force True—Specifies that the link type for the port is point-to-point link.
Transmit Limit
Configure the maximum number of MSTP packets that can be sent during each
Hello interval.
The larger the transmit limit is, the more network resources will be occupied. HP
recommends you to use the default value.
