Hangzhou H3C Technologies Co., Ltd. H3C 5820X-LSW1FC4P0-9.0.7.08.00 Release Notes H3C 5820X-LSW1FC4P0-9.0.7.08.
Hangzhou H3C Technologies Co., Ltd. H3C 5820X-LSW1FC4P0-9.0.7.08.00 Release Notes H3C 5820X-LSW1FC4P0-9.0.7.08.00 Release Notes Keywords: Version Information, Version changed, Unresolved Problems and Avoidance Measures, List of Solved Problems. Abstract: Provide all details about the application version file, include: Version Information, Version changed, Unresolved Problems and Avoidance Measures, List of Solved Problems.
Hangzhou H3C Technologies Co., Ltd. H3C 5820X-LSW1FC4P0-9.0.7.08.
Hangzhou H3C Technologies Co., Ltd. H3C 5820X-LSW1FC4P0-9.0.7.08.
Hangzhou H3C Technologies Co., Ltd. H3C 5820X-LSW1FC4P0-9.0.7.08.00 Release Notes Version Information Version Number LSW1FC4P0 Version 9.0.7.08.00 Version History Table 1 Version history Version number Last version Release Date Remarks 9.0.7.08.00 9.0.6.15.0 2011-08 None 9.0.6.15.0 9.0.6.14.0 2010-09-21 None 9.0.6.14.
Hangzhou H3C Technologies Co., Ltd. H3C 5820X-LSW1FC4P0-9.0.7.08.00 Release Notes Feature List Hardware Features Table 3 Hardware features Item Specification Dimensions (H x W x D) 37 × 160 × 210 mm Weight 690 g SFP+ Interface Four (4) external SFP+ flex ports that can be configured as 10Gb CEE or 8Gb Fibre Channel Management Ethernet Port One (1) on front panel Internal Interfaces Four internal 10Gbs CEE XAUI ports Hot-pluggable, 3.
Hangzhou H3C Technologies Co., Ltd. H3C 5820X-LSW1FC4P0-9.0.7.08.00 Release Notes NPIV transparent connections to Fibre Channel fabrics 10Gb XAUI ports x 4 (internal) Ethernet Interface Compliance and Support ETS - Enhanced transmission selection (802.1Qaz) PFC - Class-based flow control (802.1Qbb) DCBX - DCB capability exchange protocol (802.
Hangzhou H3C Technologies Co., Ltd. H3C 5820X-LSW1FC4P0-9.0.7.08.00 Release Notes Version Updates Feature Updates Table 5 Feature updates Version number 9.0.7.08.00 9.0.6.15.0 9.0.6.14.0 Item Description Hardware feature updates None Software feature updates No alerts based on digital diagnostic data Hardware feature updates None Software feature updates None Hardware feature updates None Software feature updates None Command Line Updates Table 6 Command line updates Version number 9.0.
Hangzhou H3C Technologies Co., Ltd. 9.0.6.14.0 H3C 5820X-LSW1FC4P0-9.0.7.08.00 Release Notes Modified None None None New None None None Modified None None None Operation Changes Operation Changes in 9.0.7.08.00 AutoLoadBalancing AutoLoadBalancing balances host logins across TF_Ports. This feature is disabled by default, and is be enabled from within the the CLI advanced mode. AutoLoadBalancing can be very disruptive to hosts and should be used with caution.
Hangzhou H3C Technologies Co., Ltd. SymPortName H3C 5820X-LSW1FC4P0-9.0.7.08.00 Release Notes (string, max=32 chars) [Port_0] q Finished configuring attributes. This configuration must be saved (see config save command) and activated (see config activate command) before it can take effect. To discard this configuration use the config cancel command. H3C (admin-config) #> config save The config named base_config has been saved.
Hangzhou H3C Technologies Co., Ltd. H3C 5820X-LSW1FC4P0-9.0.7.08.00 Release Notes For more information about the port link-type hybrid, port hybrid vlan, and port hybrid vlan commands, refer to the H3C S5820X&S5800 Series Ethernet Switches Command Manual. Operation Changes in 9.0.6.15.0 None Operation Changes in 9.0.6.14.0 None Open Problems and Workarounds PR118211 (LSD54433) First Found in: 9.0.7.08.
Hangzhou H3C Technologies Co., Ltd. H3C 5820X-LSW1FC4P0-9.0.7.08.00 Release Notes [Potential misconfiguration: TF ports of the same port group discovering multiple fabric names.] Workaround: None PR119702 First Found in: 9.0.7.08.00 Description: PLOGIs coming into the switch module should be verified from their S_ID as acceptable PLOGIs before they are routed to the fabric. This behavior is not happening, and unacceptable PLOGIs may be routed thru to the fabric.
Hangzhou H3C Technologies Co., Ltd. H3C 5820X-LSW1FC4P0-9.0.7.08.00 Release Notes Resolved Problems in 9.0.6.15.0 LSD51785 First Found in: 9.0.6.14.0 Condition: Modify the LLDP encapsulation type of internal port to snap mode. Description: LSW1FC4P0 takes long time to check LLDP neighbor state change. LSD51815 First Found in: 9.0.6.14.0 Condition: Modify the SymPortName of port longer than 15 chars, Description: The interface name in LLDP packet may be error. LSD52085 First Found in: 9.0.6.14.
Hangzhou H3C Technologies Co., Ltd. H3C 5820X-LSW1FC4P0-9.0.7.08.00 Release Notes H3C LSW1FC4P0 Interface Card for S5820X-28C Ethernet Switches Install Guide 5PW102 H3C LSW1FC4P0 Interface Card for S5820X-28C Ethernet Switches Quick Tools Guide 59273-00 C Software Upgrading Introduction The LSW1FC4P0 card has its own firmware apart from the S5820X-28C Ethernet switch. To install new firmware on the LSW1FC4P0 card, you can use the CLI or the QuickTools web applet.
Hangzhou H3C Technologies Co., Ltd. 4. H3C 5820X-LSW1FC4P0-9.0.7.08.00 Release Notes QuickTools prompts you to activate the new firmware using a hot (non-disruptive) reset, if possible. Click OK to reset the switch and activate the new firmware. Using the CLI to Install Firmware The method you choose to install firmware using the CLI depends on the type of firmware activation you want.
Hangzhou H3C Technologies Co., Ltd. 3. H3C 5820X-LSW1FC4P0-9.0.7.08.00 Release Notes Enter your account name on the remote host (FTP only) and the IP address of the remote host. When prompted for the source file name, enter the path for the firmware image file. User Account : johndoe IP Address : 10.0.0.254 Source Filename : 9.0.xx.xx_Flcn About to install image. Do you want to continue? [y/n] y 4. When prompted to install the new firmware, enter Yes to continue or No to cancel.
Hangzhou H3C Technologies Co., Ltd. H3C 5820X-LSW1FC4P0-9.0.7.08.00 Release Notes H3C (admin) $>image unpack filename 4. Wait for the unpack to complete. image unpack command result: Passed 5. A message will prompt you to reset the interface card to activate the firmware. Enter the Hotreset command to attempt a non-disruptive activation. H3C (admin) $>hotreset Copyright © 2010, 2011 Hangzhou H3C Technologies Co., Ltd. All rights reserved.
