196 CHAPTER 5: USING ROUTING PROTOCOL COMMANDS
Example
View the information of the peer group aaa.
<SW7700>display bgp group aaa
group : aaa no as-number still
members in this group :
Description : aaa
route-policy specified in export policy : aaa
filter-policy specified in export policy : list no.30304410
acl specified in export policy : list no.30304410
ip-prefix specified in export policy : aaa
route-policy specified in import policy : aaa
filter-policy specified in import policy : list no.30304410
acl specified in import policy : list no.30304410
ip-prefix specified in import policy : aaa
with Route-policy aaa
display bgp network Syntax
display bgp network
View
All views
Parameter
none
Description
Use the display bgp network command to view the routing information that has
been configured.
Example
Display the routing information that has been configured.
<SW7700>display bgp network
Network Mask Route-policy
133.1.1.0 255.255.255.0 None
112.1.0.0 255.255.0.0 None
Tab le 9 Description of information generated by the command display bgp group
Field Description
group Name of peer group and AS number
members in this group Members in this peer group
route-policy Name of configured route policy
filter-policy Configured export and import route filter for BGP
acl Configured access control list
ip-prefix Configured IP address prefix list
