6
USING MULTICAST PROTOCOL
COMMANDS
This chapter describes how to use the following commands:
GMRP Configuration Commands
■ debugging gmrp
■ display gmrp statistics
■ display gmrp status
■ gmrp
IGMP Snooping Configuration Commands
■ display igmp-snooping configuration
■ display igmp-snooping group
■ display igmp-snooping statistics
■ igmp-snooping
■ igmp-snooping host-aging-time
■ igmp-snooping max-response-time
■ igmp-snooping router-aging-time
■ reset igmp-snooping statistics
Multicast Common Configuration Commands
■ debugging multicast forwarding
■ debugging multicast kernel-routing
■ debugging multicast status-forwarding
■ display multicast forwarding-table
■ display multicast routing-table
■ display multicast vif
■ multicast routing-enable
PIM Configuration Commands
■ register-policy
■ c-bsr
■ c-rp
■ debugging pim common
■ debugging pim dm
■ debugging pim sm
