Switch 7700 Command reference Guide, v2.0

28 CHAPTER 1: USING SYSTEM ACCESS COMMANDS
The information is displayed in the following format:
Idx Type Tx/Rx Modem Privi Auth
I 0 AUX 0 9600 3 N
* : Current user-interface is active.
I : Current user-interface is active and work in async mode.
Idx : Absolute index of user-interface.
Type : Type and relative index of user-interface.
Privi: The privilege of user-interface.
Auth : The authentication mode of user-interface.
A: Authenticate use AAA.
L: Authenticate use local database.
N: Current user-interface need not authentication.
P: Authenticate use current UI's password.
The categories of information displayed are as follows:
display users Syntax
display users [ all ]
View
All views
Parameter
all: Enter to display information on all user interfaces.
Description
■ Use the display users command to view information on the current user
interface.
■ Use the display users all command to view the information on all user
interfaces.
Example
To display information on the current user interface, enter the following
[SW7700]display users
The information displays in the following format:
UI Delay IPaddress Username
I 0 AUX 0 192.168.1.250
Tab le 1 Output description of the display user-interface command
Field Description
I Indicates that the user interface in use
Idx Displays the index number of the user interface
Type Displays the type and type number of the user interface
Tx/Rx Displays the user interface speed
Modem Displays the modem operation mode
Privi Indicates the command level that can be accessed from this
user interface
Auth Indicates the user interface authentication method
