10
USING RELIABILITY COMMANDS
This chapter describes how to use the following commands:
VRRP Configuration Commands
■ debugging vrrp
■ display vrrp
■ vrrp authentication-mode
■ vrrp method
■ vrrp ping-enable
■ vrrp vrid preempt-mode
■ vrrp vrid priority
■ vrrp vrid timer
■ vrrp vrid track
■ vrrp vrid virtual-ip
HA Configuration Commands
■ display switch state
■ slave restart
■ slave switchover
■ slave update config
VRRP Configuration
Commands
This section describes how to use the Virtual Router Redundancy Protocol (VRRP)
configuration commands on your Switch 7700.
debugging vrrp Syntax
debugging vrrp { state | packet }
undo debugging vrrp { state | packet }
View
User view.
Parameter
state: debugging VRRP state
packet: debugging VRRP packets
