470 CHAPTER 11: USING SYSTEM MANAGEMENT COMMANDS
The following table describes the output fields.
CAUTION: If the SNMP Agent is disabled, "Snmp Agent disabled" will be
displayed after you execute the above display commands.
display snmp-agent
statistics
Syntax
display snmp-agent statistics
View
All views
Parameter
None
Description
Using the display snmp-agent statistics command, you can display the
current state of SNMP communication.
This command provides a counter for SNMP operations.
Example
Display the current state of SNMP communication.
<SW7700>display snmp-agent statistics
32 SNMP packets input
0 Bad SNMP version errors
4 Unknown community name
0 Illegal operation for community name supplied
0 Encoding errors
24 Number of requested variables
0 Number of altered variables
0 Get-request PDUs
28 Get-next PDUs
0 Set-request PDUs
41 SNMP packets output
0 Too big errors (Maximum packet size 1500)
0 No such name errors
0 Bad values errors
0 General errors
24 Response PDUs
13 Trap PDUs
Tab le 36 Output description of the display snmp-agent mib-view command
Field Description
View name View name
MIB Subtree MIB subtree
storage-type Storage type
included/excluded Permit or forbid access to an MIB object
active Indicate the line state in the table
