Switch 7700 Command reference Guide, v2.0

RMON Configuration Commands 485
display rmon history Syntax
display rmon history [ port-num ]
View
All views
Parameter
port-num: Ethernet port name.
Description
Using the display rmon history command, you can display latest RMON history
sampling information (including utility, error number and total packet number).
For the related commands, see rmon history.
Example
Show the RMON history information.
<SW7700>display rmon history Ethernet 2/0/1
History control entry 1 owned by 3Com is VALID, samples interface
Ethernet2/0/1 every 10 second with 10 buckets max.
Latest sampled values:
Dropevents :0 , octets :0
packets :0 , broadcast packets :0
multicast packets :0 , CRC alignment errors :0
undersize packets :0 , oversize packets :0
fragments :0 , jabbers :0
collisions :0 , utilization :0
Table 41 Output description of the display rmon eventlog command
Field Description
Event table Index 1 in event table
VALID The entry corresponding to the index is valid
3Com Owner
Description Event description
Event firing causes log-and-trap Log and trap triggered by event
last fired at 102300 Occurrence time of the latest event (counted since
system initiate/boot time in centisecond)
Table 42 Output description of the display rmon history command
Field Description
Interface Port
history control table Index number in history control table
VALID Valid
3COM Owner
buckets Records in history control table
sampling interval Sampling interval
dropevents Dropping packet events
octets Sent/Transmitted octets in sampling time
