Chapter 1: Connecting CD-
Writer Plus and Installing the
Software
7. Connecting the audio cable is OPTIONAL. If you do not wish to use it, go
to step 10.
The audio cable is used only for hearing music CDs through your
computer’s sound system. If you do not have a sound board in your
computer, you can still hear music CDs through speakers or earphones
attached to the front of the CD-Writer Plus drive.
NOTE: When the CD-Writer Plus drive records music or data, it uses the data
cable, not the audio cable.
8. If you have a sound board, connect the audio cable to a LINE IN audio
connector on the back of your computer. (Your sound board may be
labeled differently.)
9. Connect the other end of the audio cable to the audio connector on the
back of the CD-Writer Plus drive.
10. Plug in and turn ON your computer.
11. You are now ready to install the parallel port drivers and the application
software. (See “Installing the Software for Windows 95 or Windows NT
4.0” on page 1-8.)
Audio cable
Audio connector
(optional)
LINE IN connector on
sound board (Your sound
board may be labeled
differently.)
