Cisco SFS 7024D InfiniBand Interconnect Cable Management Brackets Installation Guide
Table Of Contents
Figure 2-1 Installing the Cable Management Brackets
1
2
6
4
5
8
3
7
The following list corresponds to the callouts shown in Figure 2-1.
1. Cisco SFS 7024D Series InfiniBand Interconnect (288 ports)
2. Right rear rack rail
3. Cable management brackets
4. Bottom rackmount brackets rear mounting flanges
5. Direction of view facing toward the rear of the rack
6. Left rear rack rail
7. Top rackmount bracket (quantity 2)
8. Heyclip to support a 7024D power cable (quantity four – two heyclips each side for upper
and two for lower rackmount brackets to support the power cables)
2.1 Cable Routing Options
Figure 2-2 shows the cable routing options for the Cisco SFS 7024D Cable Management Brackets.
14 Installing the Cable Management Brackets
