HP Cluster Platform 435762-B21 Cable Management Bracket Installation Guide

1 Preparing for Installation
1.1 Audience
This guide is intended for HP service representatives and other persons trained to install hardware
options in the HP Rack 10000 Series cabinet. Note that such persons are expected to understand
the hazards of working in this environment and to take suitable precautions to minimize danger
to themselves and others.
This bracket is used to support cables in either an inward or outward orientation on the following
servers:
• DL380 G4 and DL585 G2 (Quadrics, Voltaire, and Cisco only)
• DL380 G5 riser cage B PCI-e (optional) in slot 3 (Quadrics, Voltaire, and Cisco only)
• DL385 G2 riser cage B PCI-e (optional) in slot 3 (Quadrics, Voltaire, and Cisco only)
• RX2660 riser cage B PCI-X (3 PCI-X slots) in slot 3 (Quadrics, Voltaire, and Cisco only)
1.2 Documentation Resources
You can download the documentation for components referenced in this installation guide from
the following locations:
• HP Rack 10000 Series Support & Documents:
http://h18004.www1.hp.com/products/servers/proliantstorage/racks/10000series/
documentation.html
• HP Cluster Platform:
http://www.hp.com/techservers/clusters/xc_clusters.html
• High Performance Computing Documentation:
http://www.docs.hp.com/en/highperfcomp.html
1.3 Revision History
Table 1-1 Revision History
DescriptionEditionDate
New version; supersedes HP Cluster Platform ACO89A Cable Management Bracket
Installation Guide (part number AC089A-doc)
Third EditionOctober 2008
Published as HP Cluster Platform ACO89A Cable Management Bracket Installation
Guide (part number AC089A-doc), superseding HP Cluster Platform ProLiant
Second EditionOctober 2007
DL380 G4 Cable Management Bracket Installation Guide (part number
AA-RWNCA-TE)
Published as HP Cluster Platform ProLiant DL380 G4 Cable Management Bracket
Installation Guide (part number AA-RWNCA-TE)
First EditionDecember 2004
1.4 Kit Description
The 435762-B21 cable management bracket described in this document is designed to align and
support cables that lead from a cluster's system interconnect to the PCI interface card installed
in each server (node). This bracket provides strain relief for the PCI port and ensures a good
connection. It also ensures the correct bend radius for the cable and provides attachment points
for cable routing and cable management. A kit is required for every server that contains a PCI
interface card for the system interconnect.
