HP Cluster Platform 435762-B21 Cable Management Bracket Installation Guide

Table 1-2 Fasteners (continued)
Cage nut for M6 x 16-mm screw.N/ASquare nutM61
Cage nut for 10-32 x .375-inch screw.N/ASquare nut10-322
• Packaging and documentation.
To prevent screws from becoming loose because of vibration, HP recommends that you use a
torque screwdriver set to the torque specifications given in Table 1-2. Contact your HP sales
representative if any parts are missing.
1.6 Required Resources
To install the kit, you need the following resources:
• Tools:
— A 6-inch long #2 (medium) Phillips (Posidrive or cross-point) screwdriver, or #2 bit for
a power screwdriver.
— Cage-nut insertion tool (shipped with the rack) or a flat-bladed screwdriver.
— Marker pen or masking tape.
• Resources: A sample cable of the type used by the system interconnect.
• Environment:
— A work surface adjacent to the rack.
— A stable work platform or step stool that lets you safely reach the servers installed in
the upper part of the rack.
8 Preparing for Installation
