HP Data Protector Software Cell Manager Planning and Sizing
Table Of Contents
- Executive summary
- Solution description
- Cell Manager software topology
- IDB architecture
- Why should you configure the IDB?
- Regular IDB backups
- IDB notifications
- Limitations
- IDB Growth and Performance
- IDB key growth factors
- IDB key performance factors
- IDB key growth and performance parameters
- Influence of logging level on IDB
- Example: Changing of logging level for filesystem backup
- Influence of catalog protection on IDB
- Example: Changing of catalog protection of a backup
- Recommended usage of logging level and catalog protection
- Use different logging levels in the same cell
- Different logging levels for ObjectCopies
- Specifics for small cells
- Specifics for large cells
- Maintenance of DCBF directories
- Cell Manager hardware aspects to consider
- Cluster support for Data Protector software Cell Manager
- Security
- IDB space consumption example
- Cell Manager requirements
- For more information
Table 3: Backup datalist details and backup specifics
Sum of Files to backup: 5,0 Million
Files per directory: 500
Total Backup Capacity: 10 GB
Objects: 20
% of incremental Backup Change 5,00%
Device concurrency: 16
Log level: All
Number of copies 0
Data protection: 52 Weeks
Catalog protection: 4 Weeks
Full backups/week: 1
Incr backups/week: 40
Figure 10 is a graphical representation of the above-described scenario. It shows in the blue box to
the left which parameter in the discussed datalist influences the IDB size/growth the most.
To estimate the size of the IDB use the Internal Database Capacity Planning Tool located at:
• On the UNIX Cell Managers:
/opt/omni/doc/C/IDB_capacity_planning.xls
• On the Windows Cell Manager:
<Data_Protector_home>\docs\IDB_capacity_planning.xls
You can also use this tool to estimate the size of the IDB in environments with online databases
(Oracle, SAP R/3).
Figure 10: Backup scenario
34
