Chapter 15: Configure Virtual Hosts 182
Network Interfaces: When the “All Servers” box is checked, the virtual
host will be configured on all servers having an interface on the network
you select for this virtual host. When you add another server to the
cluster, the virtual host will automatically be configured on that server.
This option can be useful with administrative applications.
Available/Members: The Available column lists all network interfaces
that are available for this virtual host. If you are configuring the virtual
host on all servers in the cluster, move the network interface for the
primary server to the Members column. The corresponding network
interfaces on the remaining servers will then be moved to the Members
column automatically.
If you are configuring the virtual host only on certain servers, move the
appropriate network interfaces for those servers to the Members column.
The first interface you select will be the primary interface. The other
interfaces you select will be backups.
The virtual host now appears on the Management Console. The following
view is from the Virtual Hosts tab.
To add or update a virtual host from the command line, use the following
command. The first network interface specified is the primary interface;
the remaining interfaces are backups.
mx vhost add|update --policy [nofailback|autofailback]
<vhost> <network_interface> ...
