Chapter 3: Introduction to HP Clustered File System 16
Single FC Port, Dual FC Switch, Single Fabric
In this example, the fabric includes two FibreChannel switches. Servers
1–3 are connected to the first FC switch; servers 4–6 are connected to the
second switch. The FC switches are connected to two RAID arrays, which
contain multiported disks. If a switch fails, the servers connected to the
other switch will survive and access to storage will be maintained.
FC SwitchFC Switch
Server
1
Server
2
Server
3
Server
4
Server
5
Server
6
RAID Array
RAID Array
