Appendix A: Management Console Icons 271
On the Applications tab, virtual hosts and single-active monitors use the
following icons to indicate the primary and backups. Multi-active
monitors use the same icons but do not include the primary or backup
indication.
Management Console Alerts
The Management Console uses the following icons to indicate the
severity of the messages that appear in the Alert window.
