Chapter 7: Configure the SAN 69
NOTE: Because the first partition on GPT disks cannot be used by HP
Clustered File System, that partition is skipped when HP
Clustered File System assigns device identifiers to the partitions.
The first identifier, psdXp1, is assigned to partition 2, the second
identifier, psdXp2, is assigned to partition 3, and so on. The
partition numbers shown on the Disk Info window are the
numbers assigned by HP Clustered File System and will not
match the partition numbers shown by the Windows Logical Disk
Manager or Diskpart utility.
Storage Summary
The Storage Summary window shows information about the PSFS
filesystems configured on the cluster and also lists the LUNs that are
currently unused and available for filesystems. To see the window, select
Storage > Storage Summary on the HP Management Console or click the
Storage icon on the toolbar.
