R21xx-HP FlexFabric 11900 IP Multicast Configuration Guide

113
Ste
p
Command Remarks
2. Enter MLD-snooping view.
mld-snooping N/A
3. Set the aging timer for
dynamic router ports globally.
router-aging-time interval The default setting is 260 seconds.
4. Set the aging timer for
dynamic member ports
globally.
host-aging-time interval The default setting is 260 seconds.
Setting the aging timers for the dynamic ports in a VLAN
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter VLAN view.
vlan vlan-id N/A
3. Set the aging timer for
the dynamic router ports
in the VLAN.
mld-snooping router-aging-time
interval
The default setting is 260 seconds.
4. Set the aging timer for
the dynamic member
ports in the VLAN.
mld-snooping host-aging-time
interval
The default setting is 260 seconds.
Configuring static ports
If all hosts attached to a port are interested in the IPv6 multicast data addressed to a particular IPv6
multicast group or the IPv6 multicast data that a particular IPv6 multicast source sends to a particular IPv6
multicast group, you can configure the port as a static member port for the specified IPv6 multicast group
or the specified IPv6 multicast source and group.
You can also configure a port as a static router port, through which the switch can forward all IPv6
multicast traffic it receives.
When you configure static ports, follow these guidelines:
• A static member port does not respond to queries from the MLD querier. When you configure a port
as a static member port or cancel this configuration on the port, the port does not send unsolicited
MLD reports or MLD done messages.
• Static member ports and static router ports never age out. To remove such a port, use the
corresponding undo command.
To configure static ports:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter Layer 2 Ethernet
interface view or Layer 2
aggregate interface view.
interface interface-type
interface-number
N/A
