R21xx-HP FlexFabric 11900 IP Multicast Configuration Guide

115
Configuring MLD snooping policies
Before you configure MLD snooping policies, complete the following tasks:
• Enable MLD snooping for the VLAN.
• Determine the ACL used as the IPv6 multicast group filter.
• Determine the maximum number of IPv6 multicast groups that a port can join.
Configuring an IPv6 multicast group filter
When you configure an IPv6 multicast group filter, follow these guidelines:
• This configuration is effective for the IPv6 multicast groups that the port dynamically joins. If you
configure the port as a static member port for an IPv6 multicast group, this configuration is not
effective for the IPv6 multicast group.
• You can configure an IPv6 multicast filter either for the current port in proper interface view or
globally for all ports in MLD-snooping view. If the configurations are made in both interface view
and MLD-snooping view, the configuration made in interface view takes priority.
Configuring an IPv6 multicast group filter globally
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter MLD-snooping view.
mld-snooping N/A
3. Configure an IPv6 multicast
group filter globally.
group-policy acl6-number [ vlan
vlan-list ]
By default, no IPv6 multicast group
filter is configured. That is, a host
can join any valid IPv6 multicast
group.
Configuring an IPv6 multicast group filter on a port
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter Layer 2 Ethernet
interface view or Layer 2
aggregate interface view.
interface interface-type
interface-number
N/A
3. Configure an IPv6 multicast
group filter for the port.
mld-snooping group-policy
acl6-number [ vlan vlan-list ]
By default, no IPv6 multicast group
filter is configured for the port. That
is, the hosts on this port can join
any valid IPv6 multicast group.
