Configuring an IPv6 multicast data filter
In either an IPv6 PIM-DM domain or an IPv6 PIM-SM domain, routers can check passing-by IPv6
multicast data and determine whether to continue forwarding the IPv6 multicast data based on the
configured filtering rules. You can configure an IPv6 PIM router to act as an IPv6 multicast data filter to
help implement traffic control and control the information available to downstream receivers.
A filter can filter not only independent IPv6 multicast data but also IPv6 multicast data encapsulated in
register messages. Generally, a filter nearer to the IPv6 multicast source has a more remarkable filtering
effect.
To configure an IPv6 multicast data filter:
Ste
p
Command Remarks
1. Enter system view.
system-view
N/A
2. Enter IPv6 PIM view.
ipv6 pim N/A
3. Configure an IPv6 multicast
data filter:
source-policy acl6-number
By default, no IPv6 multicast data
filter is configured.
Configuring a hello message filter
Along with the wide applications of IPv6 PIM, the security requirement for the protocol is becoming
increasingly demanding. The establishment of correct IPv6 PIM neighboring relationship is a prerequisite
for secure application of IPv6 PIM.
To guard against IPv6 PIM message attacks, you can configure a legal source address range for hello
messages on interfaces of routers to ensure the correct IPv6 PIM neighboring relationship.
To configure a hello message filter:
Ste
p
Command Remarks
1. Enter system view.
system-view
N/A
2. Enter interface view.
interface interface-type
interface-number
N/A
3. Configure a hello message
filter.
ipv6 pim neighbor-policy
acl6-number
By default, no hello message filter
exists.
If an IPv6 PIM neighbor's hello
messages cannot pass the filter, the
neighbor is automatically removed
when its maximum number of hello
attempts is reached.
