Displaying and maintaining IPv6 PIM
Execute display commands in any view and reset commands in user view.
Task Command
Display BSR information in the IPv6
PIM-SM domain.
display ipv6 pim bsr-info
Display information about the
routes used by IPv6 PIM.
display ipv6 pim claimed-route [ ipv6-source-address ]
Display C-RP information in the IPv6
PIM-SM domain.
display ipv6 pim c-rp [ local ]
Display IPv6 PIM information on an
interface.
display ipv6 pim interface [ interface-type interface-number ] [ verbose ]
Display IPv6 PIM neighbor
information.
display ipv6 pim neighbor [ ipv6-neighbor-address | interface
interface-type interface-number | verbose ] *
Display IPv6 PIM routing table
information.
display ipv6 pim routing-table [ ipv6-group-address [ prefix-length ] |
ipv6-source-address [ prefix-length ] | flags flag-value | fsm |
incoming-interface interface-type interface-number | mode mode-type |
outgoing-interface { exclude | include | match } interface-type
interface-number ] *
Display RP information in the IPv6
PIM-SM domain.
display ipv6 pim rp-info [ ipv6-group-address ]
IPv6 PIM configuration examples
IPv6 PIM-DM configuration example
Network requirements
VOD streams are sent to receiver hosts in multicast. The receiver groups of different organizations form
stub networks, and one or more receiver hosts exist in each stub network. The entire IPv6 PIM domain is
operating in the dense mode.
Host A and Host C are multicast receivers in two stub networks N1 and N2.
MLDv1 runs between Switch A and N1 and between Switch B, Switch C, and N2.
