R21xx-HP FlexFabric 11900 MPLS Command Reference

121
Predefined user roles
network-admin
network-operator
Parameters
group-name: Displays peers in the peer group specified by its name, a case-sensitive string of 1 to 47
characters.
ip-address: Specifies a BGP VPNv6 peer. If no peer is specified, the command displays all BGP VPNv6
peers.
log-info: Displays log information.
verbose: Displays detailed information. If this keyword is not specified, the command displays brief
information.
Usage guidelines
With no parameters specified, this command displays brief information about all BGP VPNv6 peers.
Examples
# Display brief information about all BGP VPNv6 peers for the public network.
<Sysname> display bgp peer vpnv6
BGP local router ID: 192.168.1.135
Local AS number: 300
Total number of peers: 1 Peers in established state: 1
Peer AS MsgRcvd MsgSent OutQ PrefRcv Up/Down State
10.1.1.2 100 6 7 0 0 00:01:57 Established
Table 42 Command output
Field Descri
p
tion
BGP Local router ID Router ID of the local BGP router.
Local AS number Local AS number
Total number of peers Total number of peers
Peers in established state Number of peers in the state of established.
Peer IP address of the peer.
AS AS number of the peer.
MsgRcvd Number of messages received.
MsgSent Number of messages sent.
OutQ Number of messages waiting to be sent to the peer.
PrefRcv Number of received prefixes.
Up/Down Duration of the BGP session in the current state.
State State of the peer.
# Display detailed information about BGP VPNv6 peer 10.1.1.2.
