R21xx-HP FlexFabric 11900 MPLS Command Reference

144
Label : 65663/65663
Control Word: Disabled/Disabled
VCCV CC Type: -/-
VCCV CV Type: -/-
MTU : 1500/1500
PW Status : PW forwarding/PW forwarding
Table 49 Output description
Field Descri
p
tion
Xconnect-group Cross-connect group of the PW.
Connection Cross-connect of the PW.
PW Status Communication
PW state communicate:
• Notification method—Uses notifications to communicate PW states.
• Label withdraw method—Assigns a PW label to the PW when the AC is up
and withdraws the PW label when the AC goes down.
Control Word Control word function (not supported).
VCCV CC Type VCCV CC type (not supported).
VCCV CV Type VCCV CV type (not supported).
display l2vpn forwarding
Use display l2vpn forwarding to display cross-connect forwarding information.
Syntax
In standalone mode:
display l2vpn forwarding { ac | pw } [ xconnect-group group-name ] [ slot slot-number ] [ verbose ]
In IRF mode:
display l2vpn forwarding { ac | pw } [ xconnect-group group-name ] [ chassis chassis-number slot
slot-number ] [ verbose ]
Views
Any view
Predefined user roles
network-admin
network-operator
Parameters
ac: Displays AC forwarding information.
pw: Displays PW forwarding information.
xconnect-group group-name: Displays forwarding information for the cross-connect group specified by
its name, a case-sensitive string of 1 to 31 characters. If no group is specified, the command displays
forwarding information for all cross-connect groups.
