R21xx-HP FlexFabric 11900 MPLS Command Reference

145
slot slot-number: Displays cross-connect forwarding information on the specified card. If no card is
specified, the command displays cross-connect forwarding information on the active MPU. (In
standalone mode.)
chassis chassis-number slot slot-number: Displays cross-connect forwarding information for a card on an
IRF member device. The chassis-number argument specifies the ID of the IRF member device and the
slot-number argument specifies the slot number of the card. If this option is not specified, the command
displays cross-connect forwarding information for the active MPU of the master device. (In IRF mode.)
verbose: Displays detailed information. Without this keyword, the command displays brief information.
Examples
# Display brief AC forwarding information for all cross-connect groups.
<Sysname> display l2vpn forwarding ac
Total number of cross-connections: 3
Total number of ACs: 3
AC Xconnect-group Link ID
XGE6/0/5 srv1 vpn1 0
XGE6/0/5 srv2 vpn2 1
XGE6/0/4 vpn3 0
Table 50 Command output
Field Descri
p
tion
Total number of
cross-connections
Total number of cross-connects, including cross-connects not bound with any AC.
AC
AC type:
• Layer 3 interface such as Vlan12.
• Service instance on a Layer 2 interface, such as XGE2/1/3 srv1.
# Display detailed AC forwarding information for all cross-connect groups.
<Sysname> display l2vpn forwarding ac verbose
Xconnect-group: vpws1
Connection: actopw1
Interface: XGE1/0/1 Service Instance: 1
Link ID : 1
Access Mode : VLAN
Encapsulation: s-vid 100
Xconnect-group: vpws5
Connection: actopw2
Interface: XGE1/0/2 Service Instance: 10
Link ID : 0
Access Mode : VLAN
Encapsulation: s-vid 10
Table 51 Command output
Field Descri
p
tion
Xconnect-group Cross-connect group name.
