R21xx-HP FlexFabric 11900 MPLS Command Reference

146
Field Descri
p
tion
Connection Cross-connect name.
Service Instance The field is available only when the AC is a service instance on a Layer 2 Ethernet port.
Access Mode AC access mode: VLAN, Ethernet.
Encapsulation
Match criterion of the service instance. This field is displayed only when the AC type is
service instance on a Layer 2 interface.
# Display brief PW forwarding information for all cross-connect groups.
<Sysname> display l2vpn forwarding pw
Total number of cross-connections: 1
Total number of PWs: 2, 2 up, 0 blocked, 0 down
Xconnect-group In/Out Label NID Link ID State
vpn1 65663/65663 131 0 Up
vpn1 65664/65665 133 1 Up
Table 52 Command output
Field Descri
p
tion
Total number of
cross-connections
Total number of cross-connects, including those not bound with any PW.
NID
NHLFE ID for the public tunnel that carries the PW.
If equal-cost tunnels are available, this field displays multiple NIDs.
If no tunnel is available, this field displays None.
State
PW state: Up, Down, Blocked, or BFD Defect.
Blocked indicates that the PW is a backup PW. BFD Defect indicates BFD has
detected a defect on the PW.
# Display detailed PW forwarding information for all cross-connect groups.
<Sysname> display l2vpn forwarding pw verbose
Xconnect-group: vpn1
Connection: ldp
Link ID: 1
PW Type : VLAN PW State : Up
In Label : 65660 Out Label: 65661
MTU : 1500
PW Attributes : Main
Tunnel Group ID : 0x800000460000004
Tunnel NHLFE IDs: 131
Link ID: 1
PW Type : VLAN PW State : Up
In Label : 65659 Out Label: 65663
MTU : 1500
PW Attributes : Backup
Tunnel Group ID : 0x800000060000000
Tunnel NHLFE IDs: 132
