R21xx-HP FlexFabric 11900 MPLS Command Reference

153
Peer PW ID Link ID State
102.2.2.2 2002 1 Up
ACs:
AC Link ID State
BAGG111 srv2002 0 Up
Table 60 Command output
Field Descri
p
tion
Xconnect-group Cross-connect group name.
Description
Description for the cross-connect group. If no description is configured, this field
is not displayed.
Connection Cross-connect name.
Connection ID Cross-connect ID.
State
Cross-connect group state: Up, Down, or Admin down. Admin down indicates
the cross-connect group has been shut down by the shutdown command.
Interworking IPv4 IPv4 interworking state: Enabled or Disabled.
AC AC type: Service instance on a Layer 2 interface, such as XGE1/0/3 srv1.
Related commands
xconnect-group
encapsulation
Use encapsulation to configure match criteria for a service instance.
Use undo encapsulation to remove match criteria for a service instance.
Syntax
encapsulation s-vid vlan-id [ only-tagged ]
encapsulation default
encapsulation { tagged | untagged }
undo encapsulation
Default
No match criteria are configured for a service instance.
Views
Service instance view
Predefined user roles
network-admin
Parameters
s-vid vlan-id: Matches incoming packets with the specified outer VLAN ID in the range of 1 to 4094.
only-tagged: Matches only tagged incoming packets. If this keyword is not specified when the matching
VLAN is the default VLAN, packets with the default VLAN ID or without any VLAN ID are all matched. If
