R21xx-HP FlexFabric 11900 MPLS Command Reference

168
Field Descri
p
tion
AC
AC type:
• Layer 3 interface such as Vlan12.
• Layer 2 interface and service instance, such as XGE6/0/3 srv1.
Link ID Link ID of the AC in the VSI.
# Display detailed AC forwarding information for all VSIs.
<Sysname> display l2vpn forwarding ac verbose
VSI Name: 2001
Interface: BAGG111 Service Instance: 2001
Link ID : 0
Access Mode : VLAN
Encapsulation: s-vid 2001
VSI Name: 2003
Interface: BAGG111 Service Instance: 2003
Link ID : 0
Access Mode : VLAN
Encapsulation: s-vid 2003
Interface: XGE1/5/0/1 Service Instance: 2003
Link ID : 1
Access Mode : VLAN
Encapsulation: s-vid 2003
Interface: XGE2/2/0/41 Service Instance: 2003
Link ID : 2
Access Mode : VLAN
Encapsulation: s-vid 2003
VSI Name: 2004
Interface: BAGG111 Service Instance: 2004
Link ID : 0
Access Mode : VLAN
Encapsulation: s-vid 2004
Table 64 Command output
Field Descri
p
tion
Service Instance
Service instance ID. This field is displayed only when the AC is a service instance on a
Layer 2 Ethernet interface.
Link ID Link ID of the AC in the VSI.
Access Mode AC access mode: VLAN, Ethernet.
Encapsulation
Match criterion of the service instance. This field is displayed only when the AC is a service
instance on a Layer 2 Ethernet interface.
# Display brief PW forwarding information for all VSIs.
<Sysname> display l2vpn forwarding pw
Total number of cross-connections: 2
