R21xx-HP FlexFabric 11900 MPLS Command Reference

169
Total number of VSIs: 3
Total number of PWs: 6, 5 up, 1 blocked, 0 down
VSI Name In/Out Label NID Link ID State
2001 131199/131199 132 256 Up
2003 131197/131197 131 256 Up
2004 131196/65662 131 256 Up
Table 65 Command output
Field Descri
p
tion
Total number of VSIs Total number of VSIs, including VSIs containing no PW.
NID
NHLFE ID for the public tunnel that carries the PW.
If equal-cost tunnels are available, this field displays multiple NIDs.
If no tunnel is available, this field displays None.
Link ID Link ID of the PW in the VSI.
State
PW state: Up, Down, Blocked, or BFD Defect.
Blocked indicates that the PW is a backup PW. BFD Defect indicates BFD has
detected a defect on the PW.
# Display detailed PW forwarding information for all VSIs.
<Sysname> display l2vpn forwarding pw verbose
VSI Name: aaa
Link ID: 8
PW Type : VLAN PW State : Up
In Label : 131090 Out Label: 131089
MTU : 1500
PW Attributes : Main
Tunnel Group ID : 0x1800000760000005
Tunnel NHLFE IDs: 133
Link ID: 9
PW Type : VLAN PW State : Up
In Label : 131091 Out Label: 131092
MTU : 1500
PW Attributes : Main
Tunnel Group ID : 0x1800000860000006
Tunnel NHLFE IDs: 135
Table 66 Command output
Field Descri
p
tion
Link ID Link ID of the PW in the VSI.
PW Type Data encapsulation type of the PW.
PW State
PW state: Up, Down, Blocked, or BFD Defect.
Blocked indicates that the PW is a backup PW. BFD Defect indicates BFD has
detected a defect on the PW.
