172
Examples
# Display all PW information.
<Sysname> display l2vpn pw
Flags: M - main, B - backup, H - hub link, S - spoke link, N - no split horizon
Total number of PWs: 2, 2 up, 0 blocked, 0 down
VSI Name: aaa
Peer PW ID In/Out Label Proto Flag Link ID State
1.1.1.9 500 131199/131199 LDP M 256 Up
2.2.2.9 500 131198/131199 LDP M 257 Up
Table 68 Command output
Field Descri
p
tion
Proto Protocol used to establish the PW: LDP or Static.
Flag
PW attribute flag:
• M—Primary PW.
• B—Backup PW.
• H—The PW is the hub link in the VPLS hub-spoke network (not supported).
• S—The PW is a spoke link in the VPLS hub-spoke network (not supported).
• N—Split horizon forwarding is disabled.
Link ID Link ID of the PW in the VSI.
State
PW state: Up, Down, Blocked, or BFD Defect. Blocked indicates that the PW is a
backup PW. BFD Defect indicates BFD has detected a defect on the PW.
# Display detailed information about all L2VPN PWs.
<Sysname> display l2vpn pw verbose
VSI Name: aaa
Peer: 1.1.1.9 PW ID: 500
Signaling Protocol : LDP
Link ID : 8 PW State : Up
In Label : 131199 Out Label: 131199
Wait to Restore Time: 0 sec
MTU : 1500
PW Attributes : Main
Tunnel Group ID : 0x1800000760000005
Tunnel NHLFE IDs : 133
Peer: 2.2.2.9 PW ID: 500
Signaling Protocol : LDP
Link ID : 9 PW State : Up
In Label : 131198 Out Label: 131199
MTU : 1500
PW Attributes : Main
Tunnel Group ID : 0x1800000860000006
Tunnel NHLFE IDs : 135
