Table 69 Command output
Field Descri
p
tion
Peer IP address of the peer PE to which the PW is destined.
Link ID Link ID of the PW in the VSI.
PW State
PW state: Up, Down, Blocked, or BFD Defect.
Blocked indicates that the PW is a backup PW. BFD Defect indicates BFD has detected
a defect on the PW.
Wait to Restore Time
Wait time to switch traffic from the backup PW to the primary PW when the primary
PW recovers, in seconds. If the switchover is disabled, this field displays Infinite.
This field is available when both primary and backup PW exist, and is displayed only
for the primary PW.
Remaining Time
Remaining wait time for traffic switchover, in seconds. This field is displayed after the
switchover wait timer is started.
MTU Negotiated MPU of the PW.
PW Attributes
PW attribute:
• Main—The PW is the primary PW.
• Backup—The PW is the backup PW.
• Hub link—The PW is the hub link in the VPLS hub-spoke network (not supported).
• Spoke link—The PW is a spoke link in the VPLS hub-spoke network (not supported).
• No-split-horizon—Split horizon forwarding is disabled.
VCCV CC
VCCV CC type:
• Control-Word—Control word.
• Router-Alert—MPLS router alert label.
• TTL—TTL timeout.
VCCV BFD
VCCV BFD type:
• Fault Detection with BFD—BFD packets use IP/UDP encapsulation (with IP/UDP
Headers).
• Fault Detection with Raw-BFD—BFD packets use PW-ACH encapsulation (without
IP/UDP Headers).
Tunnel Group ID ID of the tunnel group for the PW.
Tunnel NHLFE IDs
NHLFE IDs of the tunnels for the PW.
If equal-cost tunnels are available, this field displays multiple NIDs.
If no tunnel is available, this field displays None.
display l2vpn pw-class
Use display l2vpn pw-class to display PW class information.
Syntax
display l2vpn pw-class [ class-name ]
Views
Any view
