Examples
# Display brief information about all service instances.
<Sysname> display l2vpn service-instance
Total number of service-instances: 8, 8 up, 0 down
Total number of ACs: 4, 4 up, 0 down
Interface SrvID Owner LinkID State Type
XGE1/1/3 1 vpls1 1 Up VPLS
XGE1/1/3 2 vpls2 1 Up VPLS
XGE1/1/3 3 vpls3 1 Up VPLS
XGE1/1/3 4 vpls4 1 Up VPLS
XGE1/1/3 5 Up
Table 71 Command output
Field Descri
p
tion
Interface Layer 2 Ethernet interface name.
SrvID Service instance ID.
Owner
Name of the VSI bound to the service instance. If no VSI is bound, this field
is blank.
LinkID Link ID of the AC in the VSI.
State Service instance state.
Type L2VPN type of the service instance: VPLS or VPWS.
# Display detailed information about all service instances on Layer 2 Ethernet interface
Ten-GigabitEthernet 1/0/3.
<Sysname> display l2vpn service-instance interface ten-gigabitethernet 1/0/3 verbose
Interface: XGE1/0/3
Service Instance: 1
Encapsulation : s-vid 2
VSI Name : vpls1
Link ID : 1
State : Up
Service Instance: 2
Encapsulation : s-vid 1001
only-tagged
VSI Name : vpls2
Link ID : 1
State : Up
Service Instance: 3
Encapsulation : s-vid 2000
VSI Name : vpls3
Link ID : 1
State : Up
