R21xx-HP FlexFabric 11900 MPLS Command Reference

18
Maximum allowed prefix number: 4294967295
Threshold: 75%
Configured hold timer value: 180 seconds
Keepalive timer value: 60 seconds
Minimum time between advertisements: 30 seconds
Peer preferred value: 0
Routing policy configured:
No routing policy is configured
Members:
Peer AS MsgRcvd MsgSent OutQ PrefRcv Up/Down State
3::3 10 0 0 0 0 00:01:02 Connect
Table 5 Command output
Field Description
BGP peer group Name of the BGP peer group.
Remote AS number AS number of the peer group.
Type
Type of the peer groups:
• external—IBGP peer group.
• internal—EBGP peer group.
Maximum allowed prefix number Maximum number of routes allowed to learn from the peer.
Threshold
Percentage of received routes from the peer to maximum routes allowed
to learn from the peer. If the percentage is reached, the system
generates alarm messages.
Configured hold time value Configured Hold Interval in seconds.
Keepalive timer value Keepalive interval in seconds.
Minimum time between
advertisements
Minimum route advertisement interval in seconds.
Peer preferred value Preferred value specified for the routes from the peer.
Routing policy configured
Routing policy configured for the peer group.
If no routing policy is specified, this field displays "No routing policy is
configured."
Members Information of the peers included in the peer group.
Peer IPv6 address of the peer.
AS AS number of the peer.
MsgRcvd Number of messages received.
MsgSent Number of messages sent.
OutQ Number of messages to be sent.
PrefRcv Number of prefixes received.
Up/Down Lasting time of the current BGP session state.
