20
Field Description
MsgSent Number of messages sent.
OutQ Number of messages to be sent.
PrefRcv Number of prefixes received.
Up/Down Lasting time of the current BGP session state.
State Current state of the BGP session between the local router and the peer.
# Display detailed information about BGP IPv6 peer 1::2 in the VPN instance vpn1.
<Sysname> display bgp peer ipv6 vpn-instance vpn1 verbose
Peer: 1::2 Local: 1::3
Type: EBGP link
BGP version 4, remote router ID 0.0.0.0
BGP current state: Connect
BGP current event: CRTimerExpired
BGP last state: Connect
Received: Total 0 messages, Update messages 0
Sent: Total 0 messages, Update messages 0
Maximum allowed prefix number: 12345
Threshold: 23%
Minimum time between advertisements is 30 seconds
Optional capabilities:
Multi-protocol extended capability has been enabled
Route refresh capability has been enabled
Peer preferred value: 0
Table 7 Command output
Field Description
Peer IP address of the peer.
Local Local router ID.
Type
BGP connection type between the local router and the peer:
• IBGP link—IBGP connection.
• EBGP link—EBGP connection.
remote router ID Router ID of the peer.
BGP current state Current state of the BGP session between the local router and the peer.
Up for Lasting time of the BGP session.
BGP current event Current event of the BGP session between the local router and the peer.
BGP last state Previous state of the BGP session.
Received Total numbers of received messages and updates.
Sent Total numbers of sent messages and updates.
Maximum allowed prefix number Maximum number of routes allowed to learn from the peer.
