R21xx-HP FlexFabric 11900 MPLS Command Reference

24
30 SWAP 0 T 1300 1024
# Display all ILM entries on slot 3.
<Sysname> display mpls forwarding ilm slot 3
Total ILM entries: 3
Flags: T - Forwarded through a tunnel
N - Forwarded through the outgoing interface to the nexthop IP address
B - Backup forwarding information
A - Active forwarding information
InLabel Oper VRF Flag SwapLabel Forwarding Info
--------------------------------------------------------------------------------
30 SWAP 0 T 1300 1024
1279 POP 0 - - -
1407 SWAP 0 NA 1271 Vlan10 50.2.0.2
NB 1270 Tun0 0.0.0.0
Table 9 Command output
Field Descri
p
tion
Total ILM entries Total number of ILM entries.
InLabel Incoming label.
Oper
Operation type:
• POP—Pops the label.
• POPGO—Pops the label and forwards the packet to another tunnel.
• SWAP—Swaps the label.
VRF Index of a VPN instance.
Flag
Forwarding flag:
• T—Forwarded through a tunnel.
• N—Forwarded through the outgoing interface to the nexthop IP address.
• B—Backup forwarding information.
• A—Active forwarding information.
SwapLabel Outgoing label value.
Forwarding Info
Forwarding information:
• When the forwarding flag is N, the forwarding information records the
outgoing interface and the next hop.
• When the forwarding flag is T, the forwarding information records the NID.
display mpls forwarding nhlfe
Use display mpls forwarding nhlfe to display Next Hop Label Forwarding Entry (NHLFE) entries.
Syntax
In standalone mode:
display mpls forwarding nhlfe [ nid ] slot slot-number
In IRF mode:
