R21xx-HP FlexFabric 11900 MPLS Command Reference

26
--------------------------------------------------------------------------------
10 - TA - 2049
20 - TA - 2050
2048 LSP NA 2025 Vlan2 10.11.112.26
2049 LSP NA 3024 Vlan2 10.11.112.26
TB 3026 20
2050 LSP NA 3025 Vlan10 10.11.113.26
Table 10 Command output
Field Descri
p
tion
Total NHLFE entries Total number of NHLFE entries.
NID NHLFE entry index.
Tnl-Type
Tunnel type:
• LSP—Static LSP tunnel, or LSP tunnel signaled using LDP or BGP.
• GRE—GRE tunnel.
• CRLSP—Static CRLSP tunnel or CRLSP tunnel signaled using RSVP.
• - (a hyphen)—The tunnel type is invalid.
Flag
Forwarding flag:
• T—Forwarded through a tunnel.
• N—Forwarded through the outgoing interface to the nexthop IP address.
• B—Backup forwarding information.
• A—Active forwarding information.
OutLabel Outgoing label.
Forwarding Info
Forwarding information:
• When the forwarding flag is N, the forwarding information records the
outgoing interface and the next hop.
• When the forwarding flag is T, the forwarding information records the NID.
display mpls interface
Use display mpls interface to display MPLS interface information, including the interface name, interface
status, and interface MPLS MTU.
Syntax
display mpls interface [ interface-type interface-number ]
Views
Any view
Predefined user roles
network-admin
network-operator
Parameters
interface-type interface-number: Specifies an interface by the interface type and number. If you do not
specify an interface, the command displays MPLS information for all MPLS-enabled interfaces.
