Field Description
Owner
Protocol that is using the label. Possible values include LDP, BGP,
RSVP, and L2VPN.
State
Usage state of the label:
• Idle—The label is idle.
• Alloc—The label has been allocated.
• Pending—The label has been released but is still used by an LSP
entry.
• Inuse—The label has been allocated and used by an LSP entry.
display mpls lsp
Use display mpls lsp to display LSP information.
Syntax
display mpls lsp [ egress | in-label label-value | ingress | outgoing-interface interface-type
interface-number | protocol { bgp | ldp | local | rsvp-te | static | static-cr } | transit ] [ vpn-instance
vpn-instance-name ] [ ipv4-dest mask-length | ipv6 [ ipv6-dest prefix-length ] ] [ verbose ]
Views
Any view
Predefined user roles
network-admin
network-operator
Parameters
egress: Displays the LSPs taking the current LSR as the egress.
in-label label-value: Displays the LSPs using the specified label as the incoming label. The value of the
incoming label ranges from 0 to 1048575.
ingress: Displays the LSPs taking the current LSR as the ingress.
outgoing-interface interface-type interface-number: Displays the LSPs using the specified interface as the
outgoing interface. The interface-type interface-number argument specifies an interface by its type and
number.
protocol: Displays the LSPs established by a specific protocol.
bgp: Displays BGP LSPs.
Ldp: Displays LDP LSPs.
local: Displays the direct LSP.
rsvp-te: Displays CR-LSPs established by RSVP-TE. This keyword is not supported in the current version.
static: Displays static LSPs.
static-cr: Displays static CR-LSPs. This keyword is not supported in the current version.
transit: Displays the LSPs taking the current LSR as a transit LSR.
