Table 12 Command output
Field Descri
p
tion
FEC
Forwarding equivalence class:
• IP address/mask—Classifies FECs by destination address.
• IP address—Classifies FECs by next hop.
• IP address/Out Label—Classifies FECs by next hop and outgoing
label.
• Ingress LSR ID/Tunnel ID/LSP ID—RSVP TE FEC.
• - (a hyphen)—The LSP is a static transit LSP or a static egress LSP.
• Backup—If the LSP is a backup LSP of the previous LSP, this field
displays "Backup."
Proto
Label distribution protocol:
• LDP.
• BGP.
• Static.
• Local—The LSP is a direct LSP.
In/Out Label Incoming label/outgoing label.
Interface/Out NHLFE
Outgoing interface name or NHLFE entry index.
NHLFEnumber specifies the outer LSP that carries the current LSP. The
outer LSP is that matches the NHLFE entry with an NID of number.
# Display IPv6 LSP information.
<Sysname> display mpls lsp ipv6
FEC : 100:100:100:100:100:100:100:100/128
Protocol : BGP In-Label : 2050
Out-Label: 10003 Out-Interface: Vlan10
BkLabel : 10004 BkInterface : Vlan20
Table 13 Command output
Field Descri
p
tion
FEC
Forwarding equivalence class:
• IP address/mask—Classifies FECs by destination address.
• IP address—Classifies FECs by next hop.
• IP address/Out Label—Classifies FECs by next hop and outgoing
label.
• Ingress LSR ID/Tunnel ID/LSP ID—RSVP TE FEC.
• - (a hyphen)—The LSP is a static transit LSP or a static egress LSP.
Protocol
Label distribution protocol:
• LDP.
• BGP.
• Static.
• Local—Direct LSP.
BkLabel Outgoing label of the backup LSP.
BkInterface Outgoing interface of the backup LSP.
