# Display detailed information for all LSPs.
<Sysname> display mpls lsp verbose
Destination : 56.10.10.2
FEC : 56.10.10.2/32
Protocol : LDP
LSR Type : Egress
Service : Statistics
In-Label : 1024
State : Active
Destination : 56.10.10.4
FEC : 56.10.10.2/32
Protocol : LDP
LSR Type : Transit
Service : -
In-Label : 1026
Path ID : 0x40000000.1
State : Active
Out-Label : 1800
Nexthop : 10.1.1.2
Out-Interface: Vlan10
Destination : 56.10.10.4
FEC : 56.10.10.2/32
Protocol : LDP
LSR Type : Ingress
Service : -
NHLFE ID : 2000
State : Active
Out-Label : 1800
Nexthop : 10.1.1.2
Out-Interface: Vlan10
Table 14 Command output
Field Descri
p
tion
Destination LSP destination address.
FEC
Forwarding equivalence class:
• IP address/mask—Classifies FECs by destination address.
• IP address—Classifies FECs by next hop.
• IP address/Out Label—Classifies FECs by next hop and outgoing label.
• Ingress LSR ID/Tunnel ID/LSP ID—RSVP TE FEC.
• - (a hyphen)—The LSP is a static transit LSP, static egress LSP, static transit
CR-LSP, or static egress CR-LSP.
