RSVP CRLSP 0/0/0 0/0/0
BGP LSP 0/0/0 0/0/0
Local LSP 2/0/0 2/0/0
-----------------------------------------------------
Total 4/2/1 4/2/1
Table 15 Command output
Field Descri
p
tion
LSP Type
LSP types:
• Static LSP.
• Static CRLSP.
• LDP LSP.
• Local LSP (direct LSP).
• RSVP CRLSP.
• BGP LSP.
Total Total number of LSPs.
Ingress Number of LSPs that take the local device as the ingress node.
Transit Number of LSPs that take the local device as a transit node.
Egress Number of LSPs that take the local device as the egress node.
Active Number of active LSPs of a specific type.
display mpls nid
Use display mpls nid to display the NID usage information.
Syntax
display mpls nid [ nid-value1 [ to nid-value2 ] ]
Views
Any view
Predefined user roles
network-admin
network-operator
Parameters
nid-value1: Specifies an NID in the range of 127 to 1000000. If used with the nid-value2 argument, the
nid-value1 argument represents the start NID of an NID range.
to nid-value2: Specifies the end NID of the NID range, in the range of 127 to 1000000. The value range
of the end NID varies with device models. If you specify an NID range by using the nid-value1 argument
and the to nid-value2 option, the command displays the usage information for the specified range of
NIDs.
Usage guidelines
If you do not specify any parameter, the command displays the usage information for all NIDs.
