R21xx-HP FlexFabric 11900 MPLS Command Reference

49
Table 19 Command output
Field Descri
p
tion
Link Hellos
Information about basic discovery that sends Link Hellos on
interfaces.
In a non-point-to-point network, an interface may discover
multiple peers.
Interface Interface using basic discovery.
Hello Interval Hello interval in milliseconds.
Hello Sent/Rcvd Number of Hellos sent or received on the interface.
Transport Address Local transport address.
Peer LDP ID LDP identifier of the LDP peer.
Source Address Source IP address of received Hello messages.
Transport Address
Transport address in the received Hello messages—the
transport address of the LDP peer.
Hello Hold Time
Hello hold time in seconds.
Local—Local hello hold time.
Peer—Peer hello hold time.
The negotiated hello hold time is the smaller one of the local
and peer hold time values.
Targeted Hellos
Information about extended LDP discovery that sends Targeted
Hellos to peers.
100.100.100.17 -> 100.100.100.18
(Active, Passive)
• The address before -> (100.100.100.17 in this example) is
the local LSR ID.
• The address after -> (100.100.100.18 in this example) is the
LSR ID of the peer.
• (Active) indicates that the local LSR is the Targeted Hello
sender.
• (Passive) indicates that the local LSR is the Targeted Hello
receiver.
• (Active, Passive) indicates that the local LSR is both the
Targeted Hello sender and receiver.
display mpls ldp fec
Use display mpls ldp fec to display LDP FEC-label mappings.
Syntax
display mpls ldp fec [ vpn-instance vpn-instance-name ] [ destination-address mask-length | summary ]
Views
Any view
Predefined user roles
network-admin
network-operator
